Video Configuration
Video Bit Stream
Figure 5-4 Video Bit Stream Configuration Window
Table 5-3 Video Bit Stream Configurations
Parameter Function
Main Stream
Code-Stream Type
Select from General stream and Motion stream. You can select different
encoder frame rates for different recording events.
The system supports the Active Control Frame (ACF) function. This allows
you to record in different frame rates.
For example, you can use a high frame rate to record important events, use
a lower frame rate to record scheduled events, and set a different frame rate
for recording motion detection.
Encode Mode
Select from four options for Encode Mode: H.264 (Main Profile), H.264H
(High Profile), H.264B (Baseline Profile), and MJPEG mode.
H.264: Main profile encoding mode.
H.264H: High profile encoding mode.
H.264B: Baseline profile encoding mode.
MJPEG: In this encoding mode, the video needs a larger bit stream to
guarantee the video definition. You can use the maximum bit stream value
in the Recommended Bit to get better video output.
Resolution
You can select from multiple resolutions from the drop-down list. The
recommended bit stream value is different for each resolution.
