Applicator Interface Kit Installation Guide 15
9. Click Save. The settings are saved.
Setup Mode
Use the printer navigation buttons to view and change settings.
1. Press home button
2. Navigate Menu > Settings > System Settings > Manage I/O.
3. Choose Enable.
4. From the menu, select Menu > Settings > Printing > Applicator.
About Applicator Interface IN Signals
This section describes the INPUT signals.
Note: All IN signals are asserted low and de-asserted high.
DC 24V Switches REL2com and REL4com between REL2nc,
REL2no, REL4nc and REL4no. Selecting Internal 24V
will switch REL2nc and REL4nc to REL2com and
REL4 com respectively. Selecting External 24V will
switch REL2no and REL4no to REL2com and
REL4com respectively.
Note: Users are not restricted to connect DC 24V to
these lines.
Signal Description
Startprint Starts a print job. Choose either Level or Pulse.
• Level: The printer starts printing labels when the startprint
signal is asserted and continues printing until the signal is
de-asserted.
• Pulse: The printer prints one label when the startprint signal is
asserted. The startprint signal must be de-asserted and then
asserted to print the next label.
Feed Feeds a single label. Not supported by S-Style.
Pause Toggles between Pause mode and printing. Not
supported by S-Style.
Reprint Reprints the last valid label.
Apperr1 Applicator error 1.
Apperr2 Applicator error 2.
Setting Description
