S9361A207X INTEGRATED BOILER CONTROLLERS
7 69-2751—05
Wiring Detail
Fig. 4. Spark-to-Pilot Ignition Wiring (S936X).
M533506
C
R
D
DHW
CIRCULATOR
ENVIRACOM
SYSTEM
CIRCULATOR
L1
GND
L2
DAMPER
(OPTIONAL)
INDUCER
(OPTIONAL)
24VAC
TRANSFORMER
SENSOR
DHW
T-S TAT
LIMIT
SWITCH
PRESSURE
SWITCH
PV
PV/
MV
GAS
CONTROL
SPARK IGNITER/FLAME SENSE
MV
