108
MAN0530 Issue 09 October 03 Searchline Excel
2104M0506
where: tttttttt System type. The system type displayed is one of the following:
Display Text System Type
Short Range 40m range system
Medium Range 120m range system
Long Range 200m range system
Duct Mount 0.5 - 5m range system
Note: It is not possible to change the system type. This is set during calibration and configuration of the
unit at the factory.
Path Length
The following message is displayed:
Path Length
nnnn
where: nnnn The path length in metres.
The following ranges of path length can be entered for the system types:
System Type Minimum Range (m) Maximum Range (m) Step Size (m)
Short Range 5401
Medium Range 20 120 1
Long Range 20 200 1
Duct Mount 0.5 5 0.1
Self Test
This starts the system self test process.
The following message is displayed:
Press Enter to
Perform checks
This message is displayed during the self test process after pressing Enter.
Processing Data
Please Wait
This message is displayed for three seconds at the end of a successful self test process.
Checks Passed
APPENDIX A - HANDHELD INTERROGATOR
>
>
