where:
D a single set of data is displayed.
DL a list of data is displayed - use the and keys to navigate the entries in the list.
Sub
another menu of options is displayed when this choice is selected - use the and
keys to navigate the sub menu choices.
Sw
the displayed option is immediately activated.
Tog the displayed option is toggled between three choices using the and keys.
Chapter 3 and Chapter 4 of this handbook describe how the Interrogator and menus are used
when the system is being installed/in use.
A.5.1 Main Menu
This menu consists of the following sub menu options:
Display Display gas and other unit readings.
Calibrate Install and calibrate the system, force the analogue output,
    showthecalibrationcoefcientsorshowtheinstrument
status.
Diagnose Inspect the fault and warning logs, perform a self-test or
perform a soft reset.
 Cong   Readthecongurationparametersoftheunit,updatethe
    usercongurationparameters.
Chg Mode Toggle the operating mode of the interrogator.
Power Off Switch the interrogator off.
A.5.2 Display Menu
This sub menu displays gas and other unit readings. It has the following options:
Gas Reading Display the gas type and system status.
Signal magnitude Show the level of the sample and reference signals.
Dynamic Reserve Shows the acceptable drop in signal level before beam block
occurs as a percentage of the current signal level.
S/W Version Displays the system software version and the current time and
date.
Gas Reading
Display the gas type and system status. The display is in the following format:
Excel gggggggg
rrrrrr uuuu /
where: gggggggg Gas name. For a special gas table this shows <Gnnn> where
nnnistheidentier.
