Page 44 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Parameter Description
FD_CHECK_MAP Mapped CHECK_ALM alarm conditions. Corresponds bit for bit to the
CHECK_ACTIVE. A bit on means that the corresponding alarm condition is
Mapped and is detected. A bit off means the corresponding alarm condition
is disabled and is not detected.
FD_CHECK_MASK Mask of CHECK_ALM. It corresponds to the bit of bit to CHECK_ACTIVE. A
bit on means that the condition is masked out from alarming.
FD_CHECK_ACTIVE Enumerated list of check conditions within a device.
FD_CHECK_ALM Alarm indicating check alarms. These conditions do not have a direct impact
on the process or device integrity.
FD_SIMULATE When simulation is enabled, the Field Diagnostics conditions are taken from
Diagnostic Simulate Value, or else the conditions are taken from Diagnostic
Value.
HARDWARE_REV The hardware revision number of the communications module.
SOFTWARE_REV The software revision number of the communications module.
MODEL_KEY The key number of RMA803 Remote Indicator (Example: RMA803).
MOD_PART_1 First part of the Model number information.
MOD_PART_2 Second part of the Model number information.
MOD_PART_3 Third part of the Model number information.
MOD_PART_4 Fourth part of the Model number information.
HW_SIMULATE_JUM
PER_STATE
State of Hardware Simulation Jumper (Enabled / Disabled).
INSTALL_DATE The date and time when the device is installed in the field. The date and
time is directly acquired from the FF Host.
MAINTENANCE_MO
DE
It indicates whether device is ready for maintenance. 'Chk with Oper'-
Check with operator to determine availability. ‘Avail for Maint'- The device is
available for maintenance.
INSTALL_DATE The date on which the device was installed.
SERIAL_NO The serial number of the device.
MAINTENANCE_MO
DE
Type of maintenance mode.
LICENSE_KEY The license key details.
OPTIONS_PRESENT
_RMA:31
License status of the device.
Attributes
Supported Modes The block supports the following modes:
• AUTO (Automatic)
• OOS (Out of Service).
Alarm Types The block supports standard block alarms (see section 5.2), and
discrete alarm for write lock.
