Honeywell SPM User Manual

SPM Single Point Monitor
SPM Technical Handbook
ALARM
TEST
ALARM
RESET
RELAY
DIS-
ABLE
SYSTEM
STATUS
ALARM
SPM
Single Point Monitor
MDA Scientific, Inc.
PPM0.0
98
1110 12 13
14
16
19
15
4
3
2
1
32
28
27
25
24
23
26
33
7
5
17 18
20
15
21
20
22
313029
6
1. Line power cord
2. Power port
3. 14-pin circular connector
4. Chemcassette
®
5. Guide post
6. Vent
7. Tape path
8. Main power switch
9. Green system status LED
10. Alarm test key
11. Alarm reset key
12. Red system status LED
13. Red Relay disable LED
14. Relay disable key
15. Sample inlet port
16. Alarm lamp
17. Detector head
18. Tape load lever
19. Digital display
20. Cover screw
21. Retaining ring
22. Collar fixing screw
23. Door thumbscrew
24. Exhaust port
25. Capstan assembly
26. Guide post
27. Take-up reel
28. Vent
29. Cover
30. Collar
31. Body
32. Chemkey slot
33. Fuse/fuse holder
Note: Features may vary depending
on instrument options.
