Honeywell Steam Humidifier User Manual

GETTING
STARTED
Proper Sizing of a Steam Humidier
Converting square footage to cubic volume requires multiplying the square footage by the ceiling height
(i.e. 2000 square foot space with 10 foot ceilings is 20,000 cubic feet). In general, the higher the ceilings, the
smaller the square footage space each Steam Humidier will cover since it must humidify the additional air
volume.
INCLUDE ALL SQUARE FOOTAGE OF THE HOME. FINISHED AND UNFINISHED.
Example 1: 2000 sq ft home: 8 ft ceilings = 16,000 cu ft. (2000 x 8)
Example 2: 2000 sq ft home: 10 ft ceilings = 20,000 cu ft. (2000 x 10)
Example 3: 2000 sq ft home: ½ with 8 ft ceilings, ½ with 12 ft ceilings. = 20,000 cu ft. ((1000 x 8) + (1000 x 12))
INCLUDING CEILING HEIGHT, FINISHED AND UNFINISHED SPACE WILL PROVIDE A MORE ACCURATE
SIZING FOR HUMIDIFICATION.
AHRI
Recommended
Humidity
(Gallons Per Day)
Construction Type 8,000 CU FT 12,000 CU FT 16,000 CU FT 20,000 CU FT 24,000 CU FT 28,000 CU FT 32,000 CU FT
Tight 3.3 4.3 5.4 7.5 9.6 11.7 16
Average 7.6 9.6 11.8 16 20.3 24.4 33
Loose 11.7 14.9 18.1 24.5 30.8 37.1 50
Recommended
Steam
Humidier
Construction Type 8,000 CU FT 12,000 CU FT 16,000 CU FT 20,000 CU FT 24,000 CU FT 28,000 CU FT 32,000 CU FT
Tight
9 GPD 9 GPD 9 GPD 9 GPD 12 GPD 9 GPD X2 12 GPD X2
Average
9 GPD 12 GPD 9 GPD X2 9 GPD X2 12 GPD X2 12 GPD X3 12 GPD X3
Loose
12 GPD 9 GPD X2 12 GPD X2 12 GPD X3 12 GPD X3 12 GPD X4 12 GPD X4
Steam Humidier System 69-2285—09
6

Honeywell Steam Humidifier Specifications

General

Type	Steam Humidifier
Brand	Honeywell
Power Source	Electric
Weight	Varies by model
Dimensions	Varies by model
Control	Digital
Voltage	120V or 240V (depending on model)
Output	Varies by model
Tank Capacity	Varies by model
