TB7100A1000 MULTIPRO™ MULTISPEED AND MULTIPURPOSE THERMOSTAT
62-0273—05 8
SETTING CALENDAR AND TIME
This thermostat is designed to, under normal use,
automatically keep current time and day in memory for up
to ten years once the calendar is set. There are two ways
to set the calendar and time for this thermostat:
SETTING DATE/TIME WHEN THERMOSTAT IS FIRST POWERED
When the thermostat is first powered, the display is ready
to set the calendar and time. The thermostat proceeds
through a sequence of setup screens. See Fig. 25.
SETTING DATE/TIME AFTER THERMOSTAT IS ALREADY
FUNCTIONING
Use the installer setup to set year, month and day. See
the Installer Setup Numbers, Settings, and Tests section.
Fig. 25. Setting calendar and time after initial powerup.
ADVANCED SETTINGS
The thermostat has advanced settings to match the HVAC
system. These settings can be adjusted to match specific
needs. See the following section (Installer Setup
Numbers, Settings, and Tests) for details.
M23023A
MONTH
YEAR
DAY
GO BACK KEY
GOES BACK TO
LAST SETTING
NEXT KEY
ADVANCE TO NEXT SETTING
DONE KEY
ADVANCES TO TIME SETTING
SCREEN AND HOME SCREEN
UP AND DOWN KEYS
CHANGES MONTH, DAY,
YEAR AND TIME
