63-2674—01 16
3. Place the thermostat back on
its base:
a. Align the terminal screw
blocks with the pins on the
back of the thermostat.
b. Push the thermostat
straight onto the base.
NOTES:
— After two minutes, the
device automatically
returns to the main
screen.
— To return to the main
screen before the two
minutes pass, press a
key.
M22259
BACK OF THERMOSTAT
BATTERY HOLDER
BATTERIES (2)
