Page 20 Combining the Modules
INSTALLATION
Combining the Modules
Each TemaKey consists of one or more RTU modules that must be
positioned and connected to their respective wall attachment frames (RTU-
Sxx) as indicated in the table below.
Reader
Code Grouping Horizontal Vertical Notes
TK-S07
1 x RTU-B07
1 x RTU-S01
Weight=0.45Kg
Power=0.8W
Current=60mA
TK-S012
1 x RTU-B12
1 x RTU-S01
Weight=0.45Kg
Power=1.0W
Current=90mA
Keyboards
Code Grouping Horizontal Vertical Notes
TK-S31
1 x RTU-T01
1 x RTU-S01
Weight=0.4Kg
Power=0.4W
Current=30mA
Display
Code Grouping Horizontal Vertical Notes
TK_S21
1 x RTU-C01
1 x RTU-S01
NO
Weight=0.45Kg
Power=1.9W
Current=140mA
TK-S22
To Next Page
