Applying the Entry/Exit Labels
Apply the two entry/exit labels to the magnetic reader according to the pre-
configured transit direction. Make sure that you place the labels in the
appropriate hollows (see details in Figure 12 and Figure 13).
IN
OUT
Å EXIT ENTRY Æ
Figure 12: Entry/exit labels
OUT
IN
Å ENTRY EXIT Æ
Figure 13: Entry/exit labels
