Honeywell TemaKey User Manual

Page 28 RTU-B12 (Proxy Reader for MIFARE Cards)
RTU-B12 (Proxy Reader for MIFARE Cards)
Code 1500119
Parameter Value
DC power supply 12V
DC
±15% 90mA
Weight 0.30 Kg
Dimensions 72 x 160 x 52 mm
IP Protection Rating IP55
Operating temperature 0-50 °C
Proxy receiver /
Trasmitter
13.56MHz RX/TX
for MIFARE (ISO14443-2A) cards
LONWORKS
®
connection Unshielded twisted pair cable
(transceiver FTT10A, 78Kbps
Signaling 2 LED tricolor (green/red/yellow)
1 buzzer
Regulations compliance
Directive EMC 89/336/EEC, 92/31/EEC,
Directive Low Voltage 72/23/EEC, 93/68/EEC:
EN60950, EN55024, EN55022, EN 300 330
FCC ID:
HS9-RTU-B12
Service Pin
Ser vice LED
