Page 8
Arranging the Cable Tubes a
nd Junction Boxes
Arranging the Cable Tu
bes and Junction
Boxes
All the cables consist of 4 wires that
must be connected in parallel from one
node to the next. It is possi
ble to link nodes in free
topology, i.e. by means of
a star or bus configuration.
Cabling: Recommendations
Figure 2 provides an example of a
typical free topology installation.
T
em
aS
e
rver
TemaPower
Figure 2: Example of a free topology installation
