Honeywell TemaKey User Manual

Attaching the Modules to the Wall Page 23
Attaching the Modules to the Wall
All tEmaline modules are equipped with a simple attachment
mechanism; the module clicks into position without the need for tools. To
attach the module to the frame, follow these steps:
1. Check that the fitting at the back of the RTU modules is positioned
correctly.
2. Attach each RTU module to the wall-mout frame as illustrated in Figure 11.
Figure 11: Attaching the module to the wall-mount frame

Honeywell TemaKey Specifications

General

Brand	Honeywell
Model	TemaKey
Category	Touch terminals
Language	English
