RTU-B07 (Proxy Reader for HID Cards) Page 27
RTU-B07 (Proxy Reader for HID Cards)
Code 1520145
Parameter Value
DC power supply 12V
DC
±15% 60mA
Weight 0.30 Kg
Dimensions 72 x 160 x 52 mm
IP Protection Rating IP55
Operating temperature 0-50 °C
Proxy receiver For HID cards
Double-antenna receiver (bidirectional)
LONWORKS
®
connection Unshielded twisted pair cable
(transceiver FTT10A, 78Kbps
Signaling 2 LED tricolor (green/red/yellow)
1 buzzer
Regulations compliance
Directive EMC 89/336/EEC, 92/31/EEC,
Directive Low Voltage 72/23/EEC, 93/68/EEC:
EN60950, EN55024, EN55022, EN 300 330
FCC ID:
HS9-RTU-B07
Service Pin
Ser vice LED
