Honeywell UDC3500 Quick Start Guide

51-52-25-130
September 2005
Quick Start Guide for UDC3500 Controller
Step 5. Configuration Record Sheet
Enter the value or selection for each prompt on this sheet so you will have a record of how your controller was configured.
Group Prompt Function Prompt Value or Selection Factory Setting
PROP BD or GAIN 1.000
RATE MIN 0.00
RSET MIN or RSET RPM 1.00
MAN RSET 0
PROP BD2 or GAIN2 1.00
RATE 2 MIN 0.00
RSET2MIN or RSET2RPM 1.00
PROP BD3or GAIN3 1.00
RATE 3 MIN 0.00
RSET3MIN or RSET3RPM 1.00
PROP BD4or GAIN4 1.00
RATE 4MIN 0.00
RSET4MIN or RSET4RPM 1.00
CYC SEC or CYC SX3 20
CYC2SEC or CYC2SX3 20
SECURITY 0
LOCKOUT CALIB
AUTO MAN ENABLE
RUN HOLD ENABLE
LOOP 1 TUNING
SP SEL ENABLE
PROP BD or GAIN 1.000
RATE MIN 0.00
RSET MIN or RSET RPM 1.00
MAN RSET 0
PROP BD2 or GAIN2 1.00
RATE 2 MIN 0.00
RSET2MIN or RSET2RPM 1.00
PROP BD3or GAIN3 1.00
RATE 3 MIN 0.00
RSET3MIN or RSET3RPM 1.00
PROP BD4or GAIN4 1.00
RATE 4MIN 0.00
RSET4MIN or RSET4RPM 1.00
LOOP 2 TUNING
CYC SEC or CYC SX3 20
SP RAMP DISABLE
TIME MIN 3
FINAL SP 1000
HOT START DISABLE
SP RATE DISABLE
EU/HR UP 0
EU/HR DN 0
SP RAMP
SP PROG For SP Program record sheet – See User Manual
FUZZY DISABLE
ACCUTUNE DISABLE
DUPLEX MANUAL
SP CHANGE 10
KPG 1.00
CRITERIA FAST
ACCUTUN2 DISABLE
DUPLEX MANUAL
SP CHANG2 10
KPG2 1.00
CRITERIA2 FAST
AT ERROR READ ONLY
ACCUTUNE
AT ERR 2 READ ONLY
CONT ALG PID A
PIDLOOPS 1 or 2
CONT2ALG PID A
OUT OVRD DISABLE
TIMER DISABLE
PERIOD 0.01
START KEY
LWR DISP TI REM
RESET KEY
INCREMENT MINUTE
INALG1 NONE
MATH K - -
CALC HI - -
CALC LO - -
ALG1 INA - -
ALG 1 INB - -
ALG1 INC - -
PCO SEL DISABLE
PCT CO 0.200
PCT H2 - -
ATM PRESS 780.0
ALG1 BIAS - -
INALG2 NONE
ALGORITHM
MATH K2 - -
