Honeywell UDC3500 Quick Start Guide

51-52-25-130
September 2005
Quick Start Guide for UDC3500 Controller
Group Prompt Function Prompt Value or Selection Factory Setting
CALC HI - -
CALC LOW - -
ALG2 INA - -
ALG2 INB - -
ALG2 INC - -
ALG2 BIAS - -
8SEG CH1 DISABLE
X1 VALUE 0
X2 VALUE 0
X3 VALUE 0
X4 VALUE 0
X5 VALUE 0
X6 VALUE 0
X7 VALUE 0
X8 VALUE 0
Y1 VALUE 0
Y2 VALUE 0
Y3 VALUE 0
Y4 VALUE 0
Y5 VALUE 0
Y6 VALUE 0
Y7 VALUE 0
Y8 VALUE 0
8 SEG CH2 DISABLE
X9 VALUE 0
X10 VALUE 0
X11 VALUE 0
X12 VALUE 0
X13 VALUE 0
X14 VALUE 0
X15 VALUE 0
X16 VALUE 0
X17 VALUE 0
Y9 VALUE 0
Y10 VALUE 0
Y11 VALUE 0
Y12 VALUE 0
Y13 VALUE 0
Y14 VALUE 0
Y15 VALUE 0
Y16 VALUE 0
Y17 VALUE 0
TOTALIZE DISABLE
ΣXXXXXXX - -
TOT SCALE E0
TOT SCR UNLOCK
Σ RESET? NO
TOT RATE SECOND
POLYNOM DISABLE
C0 VALUE 0
C1 VALUE 0
C2 X 10
-1
0
C2 X 10
-3
0
C2 X 10
-5
0
MATH
C2 X 10
-7
0
LOG GATE DISABLE
GATE1TYP NOT USED
GATE1INA CONST K
GATE1 K 0
GATE1INB FIXED OFF
GATE1OUT ANY GATE
GATE2TYP NOT USED
GATE2INA CONST K
GATE2 K 0
GATE2INB FIXED OFF
GATE2OUT ANY GATE
GATE3TYP NOT USED
GATE3INA CONST K
GATE3 K 0
GATE3INB FIXED OFF
GATE3OUT ANY GATE
GATE4TYP NOT USED
GATE4INA CONST K
GATE4 K 0
GATE4INB FIXED OFF
GATE4OUT ANY GATE
GATE5TYP NOT USED
GATE5INA CONST K
GATE5 K 0
GATE5INB FIXED OFF
LOGIC
GATE5OUT ANY GATE
