Honeywell UDC3500 Quick Start Guide

51-52-25-130
September 2005
Quick Start Guide for UDC3500 Controller
Group Prompt Function Prompt Value or Selection Factory Setting
OUT ALG CURRENT
OUT RNG 100PCT
C1 RANGE 4-20mA
RLYSTATE 1OF2ON
RLY TYPE MECHAN
MOTOR TI 5
OUT2 ALG CURRENT
OUT2 RNG 100PCT
C3 RANGE 4-20mA
RLYSTAT2 1OF2ON
CUR OUT1 DISABLE
LOW VAL 0.0
OUTPUT
HIGH VAL 100.0
IN1 TYPE 0-10mV
XMITTER1 LINEAR
IN1 HIGH 1000
IN1 LOW 0
RATIO 1 1.00
BIAS IN1 0
FILTER 1 0
BURNOUT1 NONE
INPUT 1
EMISSIV1 0.00
IN2 TYPE 0-10mV
XMITTER2 LINEAR
IN2 HIGH 1000
IN2 LOW 0
RATIO 2 1.00
BIAS IN2 0
FILTER 2 0
BURNOUT2 NONE
INPUT 2
EMISSIV2 0.00
IN3 TYPE 0-10mV
XMITTER3 LINEAR
IN3 HIGH 1000
IN3 LOW 0
RATIO 3 1.00
BIAS IN3 0
FILTER 3 0
BURNOUT3 NONE
INPUT 3
EMISSIV3 0.00
IN4 TYPE 0-10mV
XMITTER4 LINEAR
IN4 HIGH 1000
IN4 LOW 0
RATIO 4 1.00
BIAS IN4 0
FILTER 4 0
INPUT 4
BURNOUT4 NONE
IN5 TYPE 0-10mV
XMITTER5 LINEAR
IN5 HIGH 1000
IN5 LOW 0
RATIO 5 1.00
BIAS IN5 0
FILTER 5 0
INPUT 5
BURNOUT5 NONE
PV SOURC INPUT 1
PID SETS 1 ONLY
SW VAL12 0
SW VAL23 0
SW VAL34 0
LSP’S 1 ONLY
RSP SRC NONE
AUTOBIAS DISABLE
SP TRACK NONE
PWR MODE MANUAL
PWR OUT LAST
SP HiLIM 1000
SP LoLIM 0
ACTION REVERSE
OUT RATE DISABLE
PCT/M UP 0
PCT/M DN 0
OUTHiLIM 100
OUTLoLIM 0.0
I Hi LIM 100
I Lo LIM 0
DROPOFF 0
DEADBAND 1.0
OUT HYST 0.5
FAILMODE NO LATCH
FAILSAFE 0.0
SW FAIL 0
MAN OUT 0
AUTO OUT 0
PBorGAIN GAIN
CONTROL
MINorRPM MIN
Page 4 of 6
