Honeywell UDC3500 Instruction

4 Kit Instruction 51-52-33-153 01/06
Replacement Instruction, Continued
Printed wiring board
identification
Figure 4 Optional Input Printed Wiring Board Identification
Printed wiring board
identification
Figure 5 Third Current Output Printed Wiring Board Identification
Printed wiring board
identification
Figure 6 Dual Relay Printed Wiring Board Identification
The Dual Relay Board would be in place of the Third Current Output Board shown
in Figure 5.
Continued on next page
Third Current Output
Power / Output Board
Second Input Board
Third Input Board
Battery
MCU / Input Board
