Honeywell V4730C Operating Instructions

V4730C/V8730C/V4734C · Edition 05.23
EN-12
11.3 Hi-lo regulator
Pressure feedback connection:
The high–low regulator with an M5 thread connec-
tion for pressure feedback.
Minimum regulation capacity:
0,31m
3
/h
Maximum operating pressure:
The maximum pressure P
max.
indication on the
housing of the combination gas control is the maxi-
mum pressure at which it functions safely.
However, the maximum operating pressure is limited
by the pressure range of the high–low pressure reg-
ulator concerned: 50mbar for pressure range 4–37.
Electrical connection:
The high–low coil is provided with an earth terminal.
The high–low coil is provided with quick connect
terminals suitable for 6,3mm.
Connector: DIN43650 From B
Regulator output pressure range:
Pressure
range
(mbar)
Setting
low high
4–37 4 - P
max
(P
max
< P
high
) 12–37
Electrical data:
Supply
voltage
Color of
coil
Current
(mA)
Power
consump-
tion
220/240V~,
50Hz
black 17,4/19 3/3,2
12 CERTIFICATION
12.1 Certificate download
Certificates – see www.docuthek.com
12.2 UL recognized
UL429 Electrically operated valves
13 LOGISTICS
Transport
Protect the unit from external forces (blows, shocks,
vibration).
Transport temperature: see page 10 (11 Technical
data).
Transport is subject to the ambient conditions
described.
Report any transport damage on the unit or packag-
ing without delay.
Check that the delivery is complete.
Storage
Storage temperature: see page 10 (11 Technical
data).
Storage is subject to the ambient conditions
described.
Storage time: 6months in the original packaging
before using for the first time. If stored for longer
than this, the overall service life will be reduced by
the corresponding amount of extra storage time.
14 DISPOSAL
Devices with electronic components:
WEEE Directive 2012/19/EU – Waste Electrical
and Electronic Equipment Directive
At the end of the product life (number of operat-
ing cycles reached), dispose of the packaging and
product in a corresponding recycling centre. Do not
dispose of the unit with the usual domestic refuse.
Do not burn the product.
On request, old units may be returned carriage paid
to the manufacturer in accordance with the relevant
waste legislation requirements.
© 2023 Honeywell International Inc.
We reserve the right to make technical modifications in the interests of progress.
The Honeywell Thermal Solutions family of products includes
Honeywell Combustion Safety, Eclipse, Exothermics, Hauck,
Kromschröder and Maxon. To learn more about our products, visit
ThermalSolutions.honeywell.com or contact your Honeywell Sales
Engineer.
Honeywell Process Solutions
Honeywell Thermal Solutions (HTS)
2101 CityWest Blvd
Houston, TX 77042
United States
ThermalSolutions.honeywell.com
