11 - 11
Suffix Add Suffix SUFBK2## 4-2
Clear One Suffix SUFCL2 4-2
Clear All Suffixes SUFCA2 4-2
Function Code Transmit *Enable RMVFNC0 4-3
Disable RMVFNC1 4-3
Intercharacter Delay Range 0 - 1000 (5ms increments) DLYCHR## 4-3
User Specified
Intercharacter Delay
Delay Length
0 - 1000 (5ms increments)
DLYCRX## 4-4
Character to Trigger Delay DLY_XX## 4-4
Interfunction Delay Range 0 - 1000 (5ms increments) DLYFNC## 4-4
Intermessage Delay Range 0 - 1000 (5ms increments) DLYMSG## 4-4
Data Formatter Selections
Data Format Editor *Default Data Format (None) DFMDF3 5-1
Enter Data Format DFMBK3## 5-2
Clear One Data Format DFMCL3 5-2
Clear All Data Formats DFMCA3 5-2
Data Formatter Data Formatter Off DFM_EN0 5-11
*Data Formatter On,
Not Required,
Keep Prefix/Suffix
DFM_EN1 5-12
Data Format Required,
Keep Prefix/Suffix
DFM_EN2 5-12
Data Formatter On,
Not Required,
Drop Prefix/Suffix
DFM_EN3 5-12
Data Format Required,
Drop Prefix/Suffix
DFM_EN4 5-12
Data Format Non-Match Error Tone *Data Format Non-Match Error Tone On DFMDEC0 5-12
Data Format Non-Match Error Tone Off DFMDEC1 5-12
Primary/Alternate Data Formats Primary Data Format ALTFNM0 5-12
Data Format 1 ALTFNM1 5-13
Data Format 2 ALTFNM2 5-13
Data Format 3 ALTFNM3 5-13
Single Scan Data Format Change Single Scan-Primary
Data Format
VSAF_0 5-13
Single Scan-Data Format 1 VSAF_1 5-13
Single Scan-Data Format 2 VSAF_2 5-13
Single Scan-Data Format 3 VSAF_3 5-13
External Input/Output
External Input *External Trigger Control Off EXTTRG0 6-1
External Trigger Control On EXTTRG1 6-1
*External Trigger Polarity High EXTTPO1 6-1
External Trigger Polarity Low EXTTPO0 6-1
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric entry
Page
