XNX Universal Transmitter Quick Start Guide
26
4
3
2
1
Ref
+
9
8
7
6
5
J1 HART
S1 S2
Terminal Block 1
Com
Sense
-
Local HART
IS Barrier
(optional)
HAR
T
Adaptor
Optional Local HART
IS Barrier must
be connected to J1
Ground Wire from
Sensepoint PPM
Internal Ground Lug
MPD
705
Sensepoint
Sense 7
Com 8
Ref 9
Figure 14. mV personality wiring
(Refer to the table on the preceding page for wire colors.)
