Honeywell XNX-UT Series User Manual

XNX Universal Transmitter Quick Start Guide
66
Warning Description
Ap-
plicable
Sensors
Latching /
Non-Latching
Frequency of
Diagnostic
Event History
Data
Action For Resolution
W013
Sensor Loop Failure, (Sensor is losing/has lost mA output signal. These are detected by Optima and Excel.
Optima, Excel
Latching
XNX polls sensor every 2 seconds, diagnostic frequency controlled by sensor
Sensor fault or warning code (Note 4)
Check that supply voltage is stable. Check wiring between Optima/Excel and XNX. Check loop impedance of wiring. Check that switches S3 and S4 are set correctly. If the switch settings need to be changed, power down the transmitter before changing the switch settings. Once the problem has been resolved, a soft reset must be performed for the Calibration menu to clear W013.
W014
Sensor Real Time Clock issue
Excel Non-latching
XNX polls sensor every 2 seconds, diagnostic controlled by sensor
Sensor fault or warning code (Note 4)
Reset “date and time” in Excel, re-cycle Excel power and confirm “date and time.” If not retained, remove and return to Honeywell for repair.
W015
Sensor Internal Failure
Optima, Excel
Latching and Non-latching
XNX polls sensor every 2 seconds, diagnostic frequency controlled by sensor
Sensor fault or warning code (Note 4)
Remove and return to Honeywell for repair.
Sensor has an internal software error
Excel Latching
XNX polls sensor every 2 seconds, diagnostic frequency controlled by sensor
Sensor fault or warning code (Note 4)
Cycle Excel power and confirm “fault cleared.” If not, replace sensor.
