Honeywell XNX-UT Series User Manual

XNX Universal Transmitter Quick Start Guide
9
Integral Mounting Lugs
Figure 1. Integral mounting lugs and optional pipe and ceiling mounts
1.67"
42.41 mm
5.6"
124.24 mm
6.00"
15.4 mm
7.75"
196.85 mm
4.48"
113.8 mm
0.625"
15.88mm
2.054"
52.18mm
0.945"
24mm
1.2"
31.75mm
1.768"
44.90 mm
3.176"
80.67 mm
1.768"
44.90 mm
0.55"
14.35 mm
6.138"
158.75mm
Figure 2. XNX Universal Transmitter mounting dimensions and clearances
