XNX Universal Transmitter Quick Start Guide
68
Warning Description
Ap-
plicable
Sensors
Latching /
Non-Latching
Frequency of
Diagnostic
Event History
Data
Action For Resolution
W022
mV Sensor Cali- bration Needed
mV Latching
When user changes sensor type or gas
1=new sensor, 2=changed personality, 3=changed gas
Generated after accepting a new mV sensor or changing the mV sensor type or changing the mV gas selection. This is a warning to user that a span calibration should be performed. If a span calibration is not performed, the default calibration values will be used.
W023
Low Optical Sample Signal
Excel Non-latching
XNX polls sensor every 2 seconds, diagnostic frequency controlled by sensor
Sensor fault or warning code (Note 4)
Check location for external interference or obstructions in the IR path. Check sensor for dirty windows. Check Excel alignment. Check Beam Block Low Signal Percentage setting in the transmitter.
W024
Reflex Failure Warning
ECC Latching
Dependent on sensor, typically 8 hours; Once fault is de- tected: every 15 minutes
0 ECC sensor is nearing end of life. Replace sensor.
W025
Safety variable fail warning
All Latching 2 seconds Note 3 Contact Honeyewell Analytics Service Department.

Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
