1. VACUUM ASSEMBLY
5
1.3
A B
1.2
1.4
1.6
1.1
B
ATTACH HANDLE
POSITION TOOLS
A. Handle / Hose Assembly
B. Wand
C. Vacuum Base and Dirt Cup
D. 2-in-1 Combination Tool
E. Pet Turbo Tool*
F. Extended Crevice Tool
G. Pet Upholstery Tool
H. Black Mesh Bag with Logo
Remove all parts from carton
and identify each item shown.
Make sure all parts are located
before disposing of packing
materials.
1.2 Insert handle section into vacuum base.
1.3 To remove handle press button on back of unit
and pull handle out of vacuum base.
ATTACH DIRT CUP
1.4 Place bottom of dirt cup into vacuum body first.
Pivot cup into vacuum.
1.5 For storage mode, push dusting brush all the
way down onto crevice tool.
1.6 Assemble combination tool onto post located
on side of vacuum.
NOTE: On board storage is only available for the
2-in-1 combination tool.
CARTON CONTENTS
C
D F
A
1.5
E*
H
G
