Hoover UH72405 - Wand and Tool Attachment; Specific Tool Applications

8
D-Grip Wand/Handle Release D-Grip Handle Release
3.3 3.6
3.8
3.7
3.4
3.5
3.3 Press handle
release button down to
release handle from
unit.
3.6 Push button (A) to
release handle grip.
3.8 Tools can be
attached to short wand
if desired.
3.7 Pull handle up and
out of unit.
3.4 Pull handle up and
out of unit.
3.5 Hold handle wand
by top of grip for easy
reach cleaning. Tools
can be attached to end
of wand if desired.
A
CAUTION
! !
CAUTION
! !
Ensure end hose connector is plugged into
hose port behind unit.
Ensure end hose connector is plugged into
hose port behind unit.
3.9
3.9 Simply push the attachment firmly on the end of
the wand or hose end. To remove tool, twist and pull
apart gently and return to storage.
A. Crevice Tool may be used in tight spaces,
corners and along edges in such places as dresser
drawers, upholstered furniture, stairs and
baseboards.
B. Dusting Brush may be used for furniture, table
tops, books, lamps, lighting fixtures, venetian blinds,
baseboards, shutters, and registers.
C. Push lock button in to release dusting brush and
slide down to revert to crevice mode.
D. Pet Turbo Tool may be used for upholstered
furniture, draperies, mattresses, clothing, and
carpeted stairs. (Tool varies per model*)
SELECT PROPER TOOL
2-in-1 Combination Tool
A B
C
HANDLES
D*
