Horizon Hobby E-flite Commander mPd 1.4m User Manual

EN
3
Table of Contents
Included / Recommended Equipment
Motor: 3720-800Kv Brushless Outrunner Motor, 14 pole
(SPMXAM2500)
Included Included
ESC: Avian 45 Amp Brushless ESC 3-4S (SPMXAE45A) Installed Installed
Servos:
Aileron, Rudder, Elevator, Flaps: A332 9g Sub-Micro MG Servo;
(240mm Lead).
Installed Installed
Receiver: Spektrum
™
AR631 6-Channel AS3X/SAFE
Telemetry Receiver (SPMAR631)
Installed Required
Recommended Battery: 4S 2200mAh LiPo Required Required
Recommended Battery Charger: 3-4-cell Li-Po battery
balancing charger
Required Required
Recommended Transmitter: Full range 6-channel
2.4GHz with Spektrum DSMX
®
technology with
adjustable Dual Rates.
Required Required
Specifications ...........................................................................................3
Transmitter Setup .....................................................................................4
PNP Receiver Selection and Installation ....................................................5
Battery Installation and ESC Arming ..........................................................6
Binding .....................................................................................................7
SAFE
®
Select Switch Designation BNF ......................................................8
Integrated ESC Telemetry .........................................................................8
Factory Installed Propeller Removal ..........................................................9
Model Assembly .......................................................................................9
Install the Propeller .................................................................................11
Control Direction Test ..............................................................................12
AS3X Response Test ...............................................................................13
Control Surface Centering and Adjusting a Ball Link ................................13
Control Horn and Servo Arm Factory Settings ..........................................14
Dual Rates and Control Throws ...............................................................14
Center of Gravity (CG) .............................................................................14
SAFE Select Flying Tips BNF....................................................................15
In-Flight Trimming...................................................................................15
Post Flight ..............................................................................................15
Motor Service .........................................................................................16
Servo Service .........................................................................................16
Troubleshooting Guide AS3X ...................................................................17
Troubleshooting Guide ............................................................................17
Troubleshooting Guide Continued ............................................................18
Replacement Parts ..................................................................................18
Recommended Items ..............................................................................18
Optional Parts .........................................................................................18
Important Federal Aviation Administration (FAA) Information ....................19
AMA National Model Aircraft Safety Code ................................................19
Limited Warranty ....................................................................................19
Contact Information ................................................................................20
FCC Information ......................................................................................20
IC Information .........................................................................................20
Compliance Information for the European Union ......................................21
If you own this product, you may be required to register with the FAA. For up-to-date information on how to register with the FAA, please visit https://registermyuas.faa gov/.
For additional assistance on regulations and guidance on UAS usage, visit knowbeforeyoufly.org/.
Specications
55.12 in (1400 mm)
45 in (1143 mm)
With 4S 2200mAh battery.
71oz. (2000g)
Without battery: 62oz (1770g)
Weight
