97-6331 • HOTSY 558-559 • REV. 4/06
OPERATOR’S MANUAL
PRESSURE WASHER
16
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 375005 Chassis 1
2 11-01002 Decal Natural Gas Pressure (559) 1
11-01001 Decal LP Gas Pressure (558) 1
3 834159 Decal, Hotsy Detergent 1
4 876025 Screw, 10/32 x 1/2" 2
5 799484 Nut, 10/32 Keps 2
6 824115 Vent Clip 4
7 861644 Hose Hanger 1
8 873777 Coil Insulation 1
9 834385 Hotsy Logo 2
10 875432 Switch, Pilot Indicator 1
11 981000 GFCI Power Cord 1
12 11-1048 Warnings Decal 1
13 691803 Pilot Ignitor Button 1
14 798914 Nut Ignitor Button 1
15 936603 End Ignitor Wire 1
16 936604 Side Ignitor Wire 1
17 11-1049 Instructions Decal 1
18 815319 Snap Bushing 2
19 823932 Mounting Clip 1
20 615533 Bolt 1/4" - 20 x 3/4" 2
21 333005 Front Chassis Panel 1
22 875474 Screw 1/4" - 20 x 1" 9
23 780451 Flat Washer 1/4" 9
24 876029 Strain Relief 1
25 631011 Clamp, Hose 1
26 834154 Decal Winterize 1
27 815329 Snap Bushing 2
28 630609 Retaining Clip 1
29 798932 Nut, ESNA, #10 - 24 3
30 935175 Screw #10 - 24 x 1/2" 3
31 375030 Rear Chassis Panel 1
32 859806 Grommet (Wand Holder) 1
33 241536 Coil 1
34 444438 Decal Detergent Metering 1
35 444437 Decal Water Metering 1
36 703106 Nut, 1/4" Flange 2
37 703127 Locknut, 1/2" 1
38 10-99078 Label, Motor Overload Reset 1
To Next Page
