97-6331 • HOTSY 558-559 • REV. 4/06
29
PRESSURE WASHER
OPERATOR’S MANUAL
REF. NO.PART NO. DESCRIPTION QTY.
1 928706 Connecting Rod Assembly 2
2 855889 Crankcase Cover Gasket 1
3 827324 Crankcase Cover 1
4 855893 Gasket 2
5 915630 Plug 3/8” 3
6 878575 Sight Glass 1
7 735313 Crankcase Allen Screw 4
8 827319 Crankshaft Seal 1
9 808895 Bearing 2
10 630712 Crankshaft HC165 1
11 808896 Bearing Flange 1
12 780565 Copper Washer 2
13 867008 Bearing Housing 1
14 926648 Bearing Housing O-Ring 2
15 906532 Oil Dipstick 1
16 915835 Plunger Rod 2
17 827318 Crankcase 1
18 ▼ ❖ Plunger Seal 2
19 ▼ ◆ Pressure Ring O-Ring 2
20 ▼ Pressure Ring 20 mm 2
21 ▼ ◆ V-Sleeve 20 mm 4
22 ▼ ◆ Support Ring 20 mm 4
23 ▼ Intermediate Ring 2
24 884477 Manifold Housing 1
25 780560 Washer 6
26 612699 Manifold Stud Bolt 6
27 915631 Plug Manifold 4
28 926656 O-Ring Manifold Plug 4
29 ★ Valve Cage 4
30 ★ Valve Spring 4
31 ★ Valve Plate 4
32 ★ Valve Seat 4
33 ★ Valve Seat O-Ring 4
34 735317 Hex Screw 8
35 780561 Washer Hex Screw 8
36 928463 Connecting Rod Pin 2
37 ✤ Plunger Assembly Bolt 2
38 ✤ Plunger Bolt O-Ring 2
39 ✤ Teflon Ring 2
40 ✤ Copper Spacer 2
41 ✤ Ceramic Plunger Sleeve 2
42 ✤ Copper Spacer 2
43 818575 Sight Glass O-Ring 1
NS 875526 Shaft Setscrew 6 mm x 6 mm 2
NS = Not Shown
PUMP, EXPLODED VIEW PARTS LIST
