PRESSURE WASHER
OPERATOR’S MANUAL
REF. NO. PART NO. DESCRIPTION QTY.
39 Fig. 14 Burner Assembly 1
40 715744 Coil Drain Plug 1
41 754711 Tee 3/8" 1
42 801102 Hex Nipple 3/8" x 1-1/2" 1
43 612949 Bolt 5/16" - 18 x 1" 4
44 703107 Flange Nut 5/16" - 18 4
45 784304 Motor 2.0 HP 1
46 213045 Burner Exhaust Vent 1
47 722411 Vent Insulation 1
48 860107 Vent Insulation Retaining Ring 1
49 Fig. 15 Control Box Assembly 1
50 Fig. 16 Coil Outlet Assembly 1
51 Fig. 17 Pump Assembly 1
52 613002 U-Bolt 1/4" - 20 x 1-1/4" x 2-1/4" 2
53 703106 Nut, 1/4" Flange 4
54 780452 Washer, 5/16" Flat 4
55 722418 Insulation 1
EXPLODED VIEW PARTS LIST (CONT)
To Next Page
