Hotsy 558 - Page 18

97-6331 • HOTSY 558-559 • REV. 4/06
OPERATOR’S MANUAL
PRESSURE WASHER
18
REF. NO.PART NO. DESCRIPTION QTY.
1 801126 Garden Hose Connector 1
2 873596 ✪ Detergent Injector Valve 1
3 823988 Hose Clamp 1
4 961534 Tubing 1/4" 48"
5 935159 Detergent Screen 1
6 867395 Hose 3/8" 4.5 "
7 898035 Nipple 3/8" x 3/8" Hose 2
8 823987 Clamp, Hose 2
Replacement Parts
753002 ✪ Detergent Injector Repair Kit
5
4
3
2
1
7
6
FIGURE 11 - WATER INLET ASSEMBLY
8
7
8
To Pump
