Hoymiles HMT-2250-6T User Manual

6.2 Status LED Indicator
The LED ashes ve times at start up. All green ashes (1s gap) indicate normal start up.
(1) Start-up Process
• Flashing green ve times (0.3s gap): Start-up success
• Flashing Red ve times (0.3s gap): Start-up failure
(2) Run Process
• Flashing Fast Green (1s gap): Producing power.
• Flashing Slow Green (2s gap): Producing power but one input is abnormal.
• Flashing Slow Green (4s gap): Producing power but there is no communication with DTU.
• Flashing Red (1s gap): Not producing power AC grid invalid (Voltage or frequency out of range).
• Flashing Red (0.5s gap): There is a fault except the abnormality of grid.
(3) Other Status
• Flashing Red and Green alternately: Firmware is corrupted.
© 2020 Hoymiles Power Electronics Inc. All rights reserved.
16
Three-phase Microinverter HMT-1800/2250 Troubleshooting
LED

Hoymiles HMT-2250-6T Specifications

General

Model	HMT-2250-6T
Category	Inverter
Max. Output Power	2250 W
Number of MPPTs	6
Efficiency	96.5%
Peak Power Tracking Voltage Range	16-60 V
Startup Voltage	22 V
Rated Output Power	2250 W
Rated Output Current	9.78A
Nominal Output Voltage/Range	230 V
Rated Output Voltage	230 V
Output Frequency	50/60 Hz
Cooling Method	Natural Convection
Protection Level	IP67
Maximum Input Current	12A
Ambient Temperature Range	-40°C to +60°C
Operating Temperature Range	-40°C to +60°C
