Solid-state drive
Description Spare part number
For use only on computer models with model numbers 15m-bq1xx and 15-bq1xx:
512-GB, 2280 PCIe, SS, NVMe L01301-002
256-GB, 2280 PCIe, SS, NVMe L01300-002
For use only on computer models with model numbers 15m-bq1xx and 15-bq1xx:
1-TB, 2280 M.2, PCIe3×4, SS, NVMe with TLC 908359-003
512-GB, 2280 M.2, PCIe3×4, SS, NVMe with TLC 847110-015
360-GB, 2280 M.2, PCIe3×4, SS, NVMe with TLC 917818-002
256-GB, 2280 M.2, PCIe3×4, SS, NVMe with TLC 847109-018
256-GB, 2280 M.2, SATA-3, with TLC 759848-028
128-GB, 2280 M.2, SATA-3 827560-038
Before removing the solid-state drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29).
5. Remove the battery (see Battery on page 31).
Remove the solid-state drive:
1. Remove the Phillips PM2.0×2.4 broad head screw (1) that secures the solid-state drive to
the system board.
34 Chapter 5 Removal and replacement procedures
