Power connector cable
Description Spare part number
Power connector cable 933523-001
Before removing the power connector cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29), and then remove the following components:
a. Battery (see Battery on page 31)
b. System board (see System board on page 42)
c. Speakers (see Speakers on page 49)
d. Display assembly (see Display assembly on page 51)
Remove the power connector cable:
▲
Remove the power connector cable.
Reverse this procedure to install the power connector cable.
60 Chapter 5 Removal and replacement procedures
