ClickPad
NOTE: The ClickPad spare part kit does not include the ClickPad bracket or ClickPad cable. The ClickPad
bracket is available using spare part number 924352-001. The ClickPad cable is available using spare part
number 924351-001.
Description Spare part number
For use only on computer models with model numbers 15m-bq1xx and 15-bq1xx L00657-001
For use only on computer models with model numbers 15m-bq0xx and 15-bq0xx 924341-001
Before removing the ClickPad, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29).
5. Remove the battery (see Battery on page 31).
Remove the ClickPad:
1. Release the ZIF connector (1) to which ClickPad cable is connected, and then disconnect
the ClickPad cable from the system board.
2. Detach the ClickPad cable (2) from the keyboard/top cover. (The ClickPad cable is attached to
the keyboard/top cover with double-sided adhesive.)
3. Remove the four Phillips PM2.0×3.4 (3) that secure the ClickPad bracket to the keyboard/top cover.
4. Remove the ClickPad bracket (4).
5. Remove the three Phillips PM2.0×2.2 broad head screws (5) that secure the ClickPad to the keyboard/
top cover.
40 Chapter 5 Removal and replacement procedures
