2-10

Installing the Switch

Installation Procedure

Wall Mounting

You can mount the switch on a wall with the front panel facing up.

WARNING For safe operation, please read the “Installation Precautions” on

page 2-3 and page 2-3, before mounting the switch.

Wall mount the switch with the network ports facing up or down.

Caution The switch should be mounted only to a wall or wood surface that is at least

3/4-inch (19.1 mm) plywood or its equivalent.

1. Install two 5/8-inch (15.875 mm) Number 12 wood screws, (included) into

the mounting surface, positioned 5.5 inches (140mm) apart for the 1810-

8 and 1810-8G Switch, or positioned 10 inches (254 mm) apart for the 1810-

24 and 1810-24G Switch. Use the wall anchors if necessary.

2. Position the switch over the screws, and then slide it down to lock it in

place.
