64
The BACI state contains these registers:
Name Size Radix Symbolic Action
IBUF
16 8
Input buffer; holds line status
OBUF
16 8
Output buffer; hold channel select
STATUS
16 2 Card status word
EDSIW
16 8 Enable device status interrupt word
DSRW
16 8 Device status reference word
CFCW
16 8 Character frame control word
ICW
16 8 Interface control word
ISRW
16 8 Interrupt status reset word
FIFOPUT
8 10 FIFO load index
FIFOGET
8 10 FIFO unload index
FIFOCNTR
8 10 FIFO character counter
BRKCNTR
16 10 BREAK clock counter
FIFO [0:127]
88
FIFO buffer
SPCHAR [0:255]
1 2 Special character RAM
UARTTHR
16 8
UART transmitter holding register
UARTTR
16 8
UART transmitter register
UARTRHR
16 8
UART receiver holding register
UARTRR
16 8
UART receiver register
UARTCLK
16 10 UART transmitter/receiver clock counter
CTIME
19 10 Inter-character poll time
LKO
1 2 Interface interrupt lockout flip-flop
CTL
1 2 Interface control flip-flop
FLG
1 2 Interface flag flip-flop
FBF
1 2 Interface flag buffer flip-flop
SRQ
1 2 Interface DMA service request flip-flop
The FIFO register defaults to single-character format display and entry but may be overridden with a numeric-
format switch, if desired. The other symbolic registers default to octal display but may be displayed in single-
character format by specifying the –A switch. Symbolic entry for these registers is also supported
