Using Computer Setup (F10) Utilities
Computer Setup can be accessed only by turning the computer on or restarting the system. To access the
Computer Setup Utilities menu, complete the following steps:
1. Turn on or restart the computer.
2. Repeatedly press F10 when the monitor light turns green to access the utility.
You can also press Esc to a menu that allows you to access dierent options available at startup,
including the Computer Setup utility.
NOTE: If you do not press F10 at the appropriate time, you must restart the computer and again
repeatedly press F10 when the monitor light turns green to access the utility.
NOTE: If the Computer Setup (F10) Utility is set to “fast boot”, use one of the following procedures to
access Computer Setup:
Before turning on the computer, press and hold F10. Turn on the computer and continue to hold
F10 until the Computer Setup (F10) Utility is displayed.
- or –
Follow the Windows instructions for rebooting the computer into the Computer Setup (F10) Utility.
3. A choice of ve headings appears in the Computer Setup Utilities menu: File, Storage, Security, Power,
and Advanced.
4. Use the arrow (left and right) keys to select the appropriate heading. Use the arrow (up and down) keys
to select the option you want, then press Enter. To return to the Computer Setup Utilities menu, press
Esc.
5. To apply and save changes, select File > Save Changes and Exit.
If you have made changes that you do not want applied, select Ignore Changes and Exit.
To reset to factory settings or previously saved default settings (some models), select Apply
Defaults and Exit. This option will restore the original factory system defaults.
NOTE: Not all settings shown in the following sections are available for all models
CAUTION: Do NOT turn the computer power OFF while the BIOS is saving the Computer Setup (F10) changes
because the CMOS could become corrupted. It is safe to turn o the computer only after exiting the F10 Setup
screen.
52 Chapter 5 Computer Setup (F10) Utility

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 280 G2 and is the answer not in the manual?

HP 280 G2 Specifications

General IconGeneral
Bus typeQPI
SteppingD1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli3-6100U
System bus rate4 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-6100 series
Processor socketBGA 1356
Processor threads4
Processor codenameSkylake
Processor frequency2.3 GHz
Processor cache typeSmart Cache
Configurable TDP-down7.5 W
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 4x1
Thermal Design Power (TDP)15 W
Number of processors installed1
Configurable TDP-down frequency0.8 GHz
Maximum number of PCI Express lanes12
Memory types supported by processorDDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor1866, 2133, 1600 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)1 x 4 GB
Ethernet LANYes
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantity6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Audio chipRealtek ALC221
Product typePC
Motherboard chipsetIntel® H110
On-board graphics card ID1916
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 520
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency300 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1000 MHz
Number of displays supported (on-board graphics)3
Sustainability certificatesEPEAT Silver, ENERGY STAR
Power supply180 W
Operating system installedFreeDOS
Processor codeSR2EU
Processor ARK ID88180
Processor package size42 X 24 mm
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Weight and Dimensions IconWeight and Dimensions
Depth355 mm
Width170 mm
Height358.8 mm
Weight6110 g
