HP 3PAR StoreServ 7450 - Ethernet Adapter Leds; Fibre Channel (FC) Adapter Leds; FC Adapter Leds

1 G Ethernet Adapter LEDs
Figure 14 1 G Ethernet Adapter LEDs
Table 11 1 G Ethernet Adapter LEDs
StateLED
Link speed 1Gb/sOn1 – Green LED
Link speed 100Mb/sOff
Link upOn2 – Green LED
Link activityBlinking
Link downOff
Fibre Channel (FC) Adapter LEDs
Figure 15 FC Adapter LEDs
Table 12 FC Adapter LEDs
Wake up failure (dead device) or power is not appliedOffNo lightAll ports
Not connectedOff
AmberPort speed Connected at 4GB/sec.3 fast blinks
Connected at 4GB/sec.4 fast blinks
Normal/Connected – link upOn
GreenLink status
Link down or not connectedFlashing
18 Understanding LED Indicator Status
