HP 3PAR StoreServ 7450 - Installing a Disk Drive; Removing a 3.5 Inch Disk Drive

4. To reinstall a new disk drive, see “Installing a Disk Drive” (page 36).
Figure 38 Removing a 3.5 inch disk drive
Installing a Disk Drive
CAUTION: Blank disk drive carriers are provided and must be used if all slots in the enclosure
are not filled with disk drives.
CAUTION: To avoid potential damage to equipment and loss of data, handle disk drives carefully.
NOTE: All drives in a vertical column of an LFF drive enclosure must be the same speed and
type.
Installing a 2.5 inch disk drive (SFF)
1. Press the handle latch to open the handle.
2. Insert the disk drive into the enclosure with the handle opened from the top in the vertical
position.
3. Slide the disk drive into the enclosure until it engages. Push firmly until it clicks.
36 Servicing the Storage System
