ADJUSTMENT
e.
Adjust
position
control
of
oscilloscope
so
that
baseline
is
centered
on
the
CRT.
f.
Set
oscilloscope
input
mode
to
dc.
g.
Adjust
potentiometer
A12R1
until
dc
level
of
displayed
waveform
is
OmV
+10mV.
Refer
to
Figure
5-4
which shows
well-adjusted
waveform.
Figure
5-4.
Waveform
at
A12Q11
Source.
Note
If
adjustment
is
not
successful,
see
Section
VIII
service
sheet
for
troubleshooting.
5-23.
A13
BOARD
OFFSET
ADJUSTMENT.
PURPOSE:
This
adjustment
eliminates
any
residual
dc
offset
voltage
from
the
A13
Process
Amplifier
Board
Assembly.
(1)To
AI3
TPI
(2)To
AI3
TP2
(3)
To
AI3
TP3
BNC
To
ALLIGATOR
CLIP
CABLE
OSCILLOSCOPE
0,0
C
U
e}
o
o
lo
|
|
i
I
o]
|
7/
0
-~
O
-
[e]
1
D1y
pw)
Figure
5-5.
A13
Board
Offset
Adjustment.
EQUIPMENT:
Oscilloscope
.
.......
...t
HP
180C/w1801A/w1821A
5-9
