H Specifications
Table H-1 Specifications
Temperature Range
Operating
Nonoperating
50° to 95°F
-22° to 140°F
10° to 35°C
-30° to 60°C
Relative Humidity (noncondensing)
Operating
Nonoperating (38.7°C max wet bulb)
10-90%
5-95%
10-90%
5-95%
Maximum Altitude (unpressurized)
Operating
Nonoperating
10,000 ft
30,000 ft
3048 m
9144 m
NOTE: Operating temperature is derated 1.0° C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level; no direct
sustained sunlight. Maximum rate of change is 10° C/Hr. The upper limit may be limited by the type and number of
options installed.
Shock
The level of shock the product can withstand with no
damage being incurred is 35 G peak input
acceleration during an 11-millisecond trapezoidal
shock pulse.
Vibration
Operating
Non-operating
Random vibration (0.25 G nominal):
●
5 Hz at 0.00025 G²/Hz
●
10 Hz at 0.01 G²/Hz
●
100 Hz at 0.01 G²/Hz
●
300Hz at 0.00001 G²/Hz
5 Hz to 500 Hz (0.2 G nominal)
NOTE: Listed are the levels of vibration the product can withstand with no damage being incurred. The values
represent a flat random vibration input acceleration profile across the given frequency range.
97
