Access Panel
1. Prepare the computer for disassembly (Preparation for Disassembly on page 3).
2. Remove the side cover by loosening the screw that connects the cover to the computer.
Figure 2-1 Removing the Computer Access Panel
3. Grasp the handle on the side cover and pull towards the back of the computer. Slide the cover
about 2.4 cm (1 inch) to remove it.
NOTE: You may want to lay the computer on its side to install internal parts. Be sure the side
with the access panel is facing up.
Figure 2-2 Removing the Computer Access Panel
4 Chapter 2 Removal and Replacement Procedures Microtower (MT) Chassis
