Drives
The computer supports one optical drive and one hard drive.
This section describes the procedure for replacing or upgrading the drives. A Torx T-15 screwdriver is
needed to remove and install the guide screws on a drive.
Installing Additional Drives
When installing additional drives, follow these guidelines:
●
Connect the primary SATA hard drive to the dark blue primary SATA connector on the system
board labeled SATA1 for model 500B, SATA0 for model 505B.
●
Connect the SATA optical drive to the white SATA connector on the system board labeled SATA2
on model 500B, SATA1 for model 505B.
CAUTION: To prevent loss of work and damage to the computer or drive:
If you are inserting or removing a drive, shut down the operating system properly, turn off the computer,
and unplug the power cord. Do not remove a drive while the computer is on or in standby mode.
Before handling a drive, ensure that you are discharged of static electricity. While handling a drive, avoid
touching the connector.
Handle a drive carefully; do not drop it.
Do not use excessive force when inserting a drive.
Avoid exposing a hard drive to liquids, temperature extremes, or products that have magnetic fields
such as monitors or speakers.
If a drive must be mailed, place the drive in a bubble-pack mailer or other protective packaging and label
the package “Fragile: Handle With Care.”
Drives 21
