HP 525

10
Figure 12 Installing the mounting bracket to a ceiling
(1) Nut, Length ( 4.5mm /0.18in ), Diameter ( 10mm
/
0.39in)
(2) Washer
(3) Ceilin
g
(4)
W
all-mountin
g
bracket
(5) Hex-head bolt, Length ( 32mm / 1.26in ), Wrench
size ( 6.85mm / 0.27in ), Thread size ( 3.91mm /
0.15in )
(6) Hook
Connecting the power supply
The device can be powered by using a local or PoE power supply. You can select either method as
needed. Make sure the power supply for either method is well grounded before you power on the AP.
Before you connect the local or PoE power supply, verify that the power supply is steady. You can use a
local power source, an uninterruptible power supply (UPS), or a user-supplied power generator to supply
power to the AP.
After powering on the AP, examine the AP status LED. For more information about AP LEDs, see Appendix
B LEDs."
Connecting the AP to a local power supply
The AP is not shipped with a power adapter or power cable.
The device supports both listed AC and DC power adapters marked “LPS” or limited power source. You
can connect the power port of the AP to the power source through a power adapter to supply power to
the AP as shown in Figure 13.
