HP 525 - Mounting the AP to a T-Rail

6
7. Mount the AP on the hook on the wall-mounting bracket. See callout 1 in Figure 6.
8. Pull down the AP until it clicks into place. See callout 2 in Figure 6.
Figure 6 Mounting the
AP to the wall mounting bracket
Mounting the AP to a T-rail
IMPORTANT:
The width of the T-rail must be in the range of 16 mm to 28 mm (0.63 in to 1.10 in).
