Chapter 2 Operating Your Universal Counter
Front Panel Display Messages
2-76 Operating Guide
2
1
If this condition recurs, your Counter may need servicing.
OFFS 2 FAIL
You have invoked the
OFFS 2 ?
choice from the Calibration menu item
CAL:
,
and the calibration failed.
OFFS 2 PASS
You have invoked the
OFFS 2 ?
choice from the Calibration menu item
CAL:
,
and the calibration passed.
NO GATE MENU
You currently have the VOLT PEAKS function selected and requested the Gate &
Ext Arm menu.
NO LIM MENU
You currently have the VOLT PEAKS or TOTALIZE function selected and
requested the Upper & Lower or Limit Modes menu.
NO MATH MENU
You currently have the VOLT PEAKS or TOTALIZE function selected and
requested the Scale & Offset menu.
NO REGISTERS
There are no registers which can be recalled and you selected the Recall menu.
NO STAT MENU
You currently have the VOLT PEAKS or TOTALIZE function selected and
requested the Stats menu.
NO TRIG MENU
You currently have the VOLT PEAKS function selected and requested the
Trigger/Sensitivity menu.
1
RECALL FAIL
You have requested the Counter to perform a recall (from the Recall menu) and a
hardware failure has resulted.
1
SAVE FAIL
You have requested the Counter to perform a save (from the Save & Print menu)
and a hardware failure has resulted.
TB CAL FAIL
You have invoked the
TIMEBAS?
choice from the Calibration menu item
CAL:
,
and the calibration failed.
TB CAL PASS
You have invoked the
TIMEBAS?
choice from the Calibration menu item
CAL:
,
and the calibration passed.
TI CAL FAIL
You have invoked the
TI QUIK?
or
TI FINE?
choice from the Calibration menu
item
CAL:
, and the calibration failed.
TI CAL PASS
You have invoked the
TI QUIK?
or
TI FINE?
choice from the Calibration menu
item
CAL:
, and the calibration passed.
Table 2-5. Menu Messages (continued)
Display Message Description
