Installation Guide
Installation checklist
1
Installation checklist
The HP 7683 Automatic Liquid Sampler consists of the HP G2612A ALS Interface
Board, the HP G2613A Injector Module, the optional HP G2614A Tray, and an
optional HP G1926A Bar Code Reader for the tray. The tray is installed on the
HP 6890 Plus Gas Chromatograph (GC).
Use this checklist when installing your HP 7683 Automatic Liquid Sampler and
accessories.
❐ Unpack the sampler components.
❒ Install the ALS Interface Board, if purchased.
❒ Install the tray, if purchased. See page 2.
❒ Install the injector mounting post. See page 4.
❒ Install the injector. See page 4.
❒ Install the (8 sample position) turret, if desired. See page 16.
❒ Install the bar code reader, if purchased. See page 6.
❒ Connect the cables. See page 8.
❒ When using the injector for cool on-column injection:
a. Check that the correct needle support assembly is installed. See
page 10.
b. Install the proper syringe for your column. See your Operation Guide.
❒ Configure your GC. See page 11.
❒ Test the installation by performing a trial run. See page 12.
